Clinical Example: Radial club hand with complete absence of the radius

This two week old has a high grade radial club hand with a normal opposite extremity. The presentation is unusual for a radial club, as the thumb is relatively normal, with syndactylyl and hypoplasia of the ulnar hand.


Click on each image for a larger picture


Click for larger image
Click for larger image

Priorities in management include:
  • First stage, immediate nonoperative care:
    • Elbow extension contracture:
      • Elbow passive flexion stretching exercises.
      • Elbow flexion motion may be improved indirectly by splinting to improve wrist position.
    • Wrist displacement and angulation:
      • Angulation of the wrist may be helped considerably by splinting, although ulnocarpal displacement can only be corrected with surgery.
      • Corrective splinting or casting should be undertaken immediately, which will reduce the extent of soft tissue release needed for correction.
    • Splinting/casting for weeks to months. Prolonged splinting will restrict psychomotor development and for this reason the most common interval of splinting recommended before surgery is months but not years.
    • Screening for associated medical conditions. Systemic and potential life threatening disorders are associated with radial club hand involving cardiac, renal, spine and hematopoetic systems and require screening before any surgery is undertaken.
  • Second stage, surgery:
    • Early surgery is probably better. There is a trend to proceed with surgery at or before one year of age, but preoperative corrective splinting or casting is always indicated. Surgery before age one usually requires less soft tissue release, less frequent need for carpectomy, and is followed by more physiologic widening of the distal ulna to support the carpus. Results of surgery are clearly worse when delayed to the age of three or beyond.
    • Surgical planning should include:
      • Elbow capsulotomy and triceps lengthening.
      • Osteotomy for ulnar bowing.
      • Flap transfer of distal forearm skin from the area where it is most ulnarly redundant to the area which is most radially deficient.
      • Correction of wrist alignment:
        • Wrist centralization, but if possible,
        • Buck Gramcko's wrist radialization with alignment of the distal ulna on the radial carpus and transfer of the entire radial muscle mass to the insertion of the extensor carpi ulnaris muscle, which is itself shortened by reefing. Profundus tendon transfers for wrist motor reconstruction would seem to be a good idea, but have been shown to be unreliable.
      • Later procedures for syndactyly correction and pollicization.
