Clinical Example: Open Reduction Distal Phalanx Base Fractures with Wires and Pins

Distal phalanx fractures are common and pose a variety of problems relating to the close proximity of nailbed, nerves, joint and tendon attachments and the fact that it represents a terminal vascular zone. These cases represent simple types of fixation which may be required for the small fragments of comminuted distal phalanx base fractures.
Click on each image for a larger picture


Case 1. This patient sustained a closed  comminuted fracture  of the distal phalanx with dorsal-palmar split  of the base and a completely displaced transverse fracture of the diaphysis.
Highslide
Highslide
A midline longitudinal palmar  approach was used.  This view shows a transverse pin across the dorsal proximal fragment, to be used as a path for interosseous wiring. Additional pins have been placed across each single cortex for later advancement.
Highslide
A wire was passed through the dorsal proximal pin track and then around the palmar pins. After reduction and tightening this wire, the pins were advanced to engage the dorsal cortex.
Highslide
Wiring was used to offset the strong pull of the flexor insertion.
Highslide
All pins were cut below the surface of the skin.
Highslide
Inury.
Highslide
One week postop.
Highslide
Three months postop, after removal of prominent pins in the office.
Highslide
Late appearance (ring finger)
Highslide
Midline palmar scar.
Highslide
Range of motion.
Highslide
Highslide

Case 2. This patient sustained a closed displaced distal phalanx base fracture with dorsal-palmar split and dorsal subluxation of the larger fracture fragment.
Highslide
Highslide
This was managed with two wires - a cerclage wire, passed over the dorsum in a subperiosteal plane, and an interfragmentary palmar wire. The profundus tendon was found to have avulsed from the palmar fragment, and the tendon was reattached with sutures passed around the palmar component of the cerclage wire. A temporary longitudinal  interfragmentary pin was also used (not shown).
Highslide
Highslide
