Clinical Example: Pyrolytic carbon metacarpophalangeal joint implant arthoplasty

Small joint arthoplasty has been an ongoing problem of hand surgery.  The delicate and anatomically precise joints of the fingers function within a very narrow tolerance of friction and mechanical balance of bone and soft tissue forces. Historically, rigid (metal and plastic) implants have failed because the mechanical mismatch at the bone-implant interface has resulted in implant displacement due to reactive bone remodelling. Flexible (silicone rubber) implants have failed because of implant breakage, erosive reaction to implant wear debris, and inability of flexible implants to provide rotational and lateral stability.

Pyrolytic carbon implant arthroplasty of the finger joints appears to be an improvement on previous strategies, as it mimics the normal joint mechanics, in movement, lack of wear debris and a close match to the mechanical characteristics of the finger bones.



Click on each image for a larger picture


Pyrolytic carbon implants for proximal interphalangeal joints (upper pair) and metacarpophalangeal joints (lower pair) are shown below (palmar view). Examples of proximal interphalangeal joint implants are posted here and  here.
Click for larger image
Phalangeal component on the left, metacarpal component on the right, palmar view.
Click for larger image
Lateral view.
Click for larger image
Rheumatoid metacarpophalangeal joint changes, metacarpal head.
Click for larger image
and after implant placement.
Click for larger image
Dorsal view of joint:
Click for larger image
and after implant placement.
Click for larger image
Lateral view of joint, showing chronic palmar subluxation -
Click for larger image
and after implant placement, subluxation corrected.
Click for larger image
Pre and postop radiographs.
Click for larger image
Click for larger image
Click for larger image
Click for larger image
